PEEK KT820GF30 Resin — 30% Glass Fiber Filled | Solvay KetaSpire® (Per KG)

PEEK KT820GF30 Resin — 30% Glass Fiber Filled | Solvay KetaSpire® (Per KG)

$300.00 USD
$300.00 USD
Sale Sold out
Shipping calculated at checkout.

Detailed Introduction of KT820GF30

KT820GF30 is a high-performance polyetheretherketone (PEEK) composite under Solvay's renowned KetaSpire product portfolio, engineered with 30% glass fiber reinforcement. Classified as a low-flow grade PEEK, it seamlessly combines the intrinsic superior properties of PEEK—such as exceptional heat and chemical resistance—with the enhanced mechanical strength, dimensional stability, and rigidity imparted by glass fiber. This unique formulation makes it an optimal choice for demanding applications operating in harsh industrial environments.

Core Properties:

·Thermal Performance: It delivers outstanding high-temperature resistance, with a continuous operating temperature of up to 260°C, a glass transition temperature of 150°C, a melting point of 340°C, and a heat deflection temperature of 310°C at 264 psi. This ensures consistent performance even under significant thermal fluctuations.
·Mechanical Strength: The 30% glass fiber reinforcement greatly enhances its mechanical capabilities, featuring a tensile strength of 175 MPa, a tensile modulus of 14.5 GPa, and a flexural strength of 276 MPa. It also exhibits excellent fatigue resistance, creep resistance, and a notched Izod impact strength of 85 J/m, maintaining structural integrity under both static and dynamic loads.
·Dimensional Stability: With a low linear thermal expansion coefficient of 7.8 ppm/°C (flow direction) and minimal mold shrinkage (0.2% in flow direction, 0.6% in transverse direction), it guarantees high precision of finished components.
· Chemical & Environmental Resistance: It demonstrates superior resistance to most organic solvents, acids, and bases, along with excellent hydrolysis and aging resistance. Compliant with RoHS and UL94 V-0 flame retardant standards, it can withstand multiple sterilization methods (autoclave, e-beam, ethylene oxide), meeting stringent medical and industrial hygiene requirements.
·Processing & Appearance: Available as natural/off-white pellets, it is easily processable via injection molding, extrusion, and machining. Its good biocompatibility and electrical insulation further expand its application potential in medical and electronic fields.
·Typical Applications: Leveraging its comprehensive performance, KT820GF30 is widely utilized in healthcare (surgical instruments, medical device components), automotive (engine compartment parts, electrical system components), aerospace (secondary structural components), electronics (insulating parts, semiconductor equipment accessories), and chemical processing (high-pressure pump valves, pipeline components).

⚙️ Solvay KetaSpire KT820GF30 30% Glass Fiber Reinforced PEEK

Authentic Solvay KetaSpire KT820GF30, 30% glass fiber reinforced PEEK! Continuous operating temp up to 260°C, heat deflection temp 310°C, excellent high-temp stability. Boasts 175 MPa tensile strength & 14.5 GPa rigidity, with outstanding fatigue and creep resistance.
RoHS compliant & UL94 V-0 flame retardant, resists acids, bases & solvents. Multiple sterilization compatible, ideal for medical devices. Good electrical insulation, processable via injection molding/extrusion. Perfect for automotive, aerospace & electronics. Genuine guarantee, fast delivery!
